220V Metal Fan, 135x135x38mm
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 5.000 Ft | — |
| 3–4 pcs | 4.750 Ft | 5% (−250 Ft/unit) |
| 5–10 pcs | 4.500 Ft | 10% (−500 Ft/unit) |
| 11+ pcs | 4.250 Ft | 15% (−750 Ft/unit) |
220V Industrial Fan with Metal Casing for Efficient Cooling
The 220V axial fan with dimensions 135x135x38mm ensures constant air circulation in industrial, electronic, and commercial spaces. With an airflow of 235m³/h and robust aluminum construction, this cooler offers long-term performance without the need for complex maintenance. Direct connection to the electrical grid via 2 wires, without transformers or adapters.
What you get with this product
- Continuous cooling with 235m³/h airflow — ideal for extracting hot air from electrical cabinets, industrial refrigerators, or welding equipment
- Aluminum casing resistant to shocks and corrosion — operates reliably in temperatures between -20°C and +70°C
- Quick installation via 4 pre-existing mounting holes — mounts on any flat surface without special tools
- Low power consumption of only 20W — economical 24/7 operation without a significant increase in your electricity bill
- Silent axial motor with 2700 rotations/minute — ensures constant ventilation without excessive vibrations or disturbing noise
- Directly compatible with 220V AC mains — no converters needed, connects immediately to an outlet or electrical panel
How it works and how to install it
The fan is fixed to the desired surface using the 4 mounting holes in the metal casing. The 2 wires connect directly to the 220V AC power source, observing polarity. The axial motor drives the ABS plastic blades, generating a constant airflow with an efficiency of 235m³/h. It can be mounted both for extracting hot air and for introducing cold air into enclosed spaces — the orientation is chosen according to the desired flow direction.
Frequently Asked Questions
Can it operate continuously or does it need to be turned off periodically?
The fan is designed for continuous 24/7 operation, with the motor supporting permanent duty without overheating.
Can it be used in high humidity environments or extreme temperatures?
Yes, it operates within the range of -20°C to +70°C, and the metal casing resists condensation. Just avoid direct contact with water or liquid jets.
How noisy is it during operation?
At 2700 rotations/minute, it generates a moderate noise typical of industrial axial fans, acceptable in workshops, warehouses, or technical spaces, but not recommended for bedrooms.
Technical Specifications
| Model | XNF-13538HSL |
| Dimensions | 135 x 135 x 38 mm |
| Power supply voltage | 220V AC |
| Frequency | 50 Hz |
| Rated current | 0.26 A |
| Power consumption | 20 W |
| Rotation speed | 2700 rpm |
| Airflow | 235 m³/h |
| Fan type | Axial |
| Casing material | Aluminum |
| Blade material | ABS Plastic |
| Operating temperature | -20°C to +70°C |
| Connection | 2 wires |
Warranty and Support
The product benefits from a 24-month warranty in accordance with Romanian law, covering manufacturing defects. Right of return within 30 days of purchase. Fast courier delivery throughout Romania, with protective packaging for safe transport.
