ON/OFF Motor Button BD23, 10A, Voltage 240V AC
Out of stock
-
Estimated delivery: 08 Jun - 12 Jun
BD23 Industrial Motor ON/OFF Switch for Professional Electrical Control
The BD23 motor switch is the professional solution for safe electrical control in industrial and residential environments. With a 10A capacity at 240V AC and robust polycarbonate and metal construction, it ensures fast and reliable switching of electromagnetic starters, contactors, and relays. Universal panel-mount installation, compatible with panels up to 8.5mm thick.
What you get with this product
- Safe and fast control of electrical circuits — instant ON/OFF switching with 2 locking positions for operational stability
- Universal compatibility — works with electromagnetic starters, contactors, and relays in automation systems
- Withstands impulse voltages up to 6KV — enhanced protection against network overvoltages
- Simple panel mounting — 22mm hole diameter, quick installation without special tools, suitable for panels up to 8.5mm thick
- Durable industrial construction — polycarbonate and metal casing withstands intensive wear and difficult working conditions
- Double NO contacts — 4-screw terminal configuration for secure and flexible electrical connections
How it works and how to install it
The BD23 button operates by rotating the selector between two fixed positions — ON and OFF — with a locking mechanism to maintain the selected position. The NO (normally open) contacts close upon switching, activating the connected electrical circuit. Installation is done by cutting a 22mm hole in the electrical panel, inserting the button, and securing it with the included lock nut. Electrical connections are made to the 4 screw terminals, according to the electrical diagram of the installation. Installs in maximum 15 minutes, no advanced experience required.
Frequently asked questions
Can I use the BD23 button to control a three-phase electric motor?
Yes, the button is specially designed for controlling motor starters and contactors, compatible with single-phase and three-phase circuits up to 10A.
What is the maximum panel thickness supported for mounting?
The button is mounted in panels with a maximum thickness of 8.5mm, covering most standard electrical panels.
Do I need to order the fixing nut separately?
No, the button comes fully equipped with everything needed for mounting, including the fixing nut and integrated contacts.
Technical specifications
| Thermal current (Ith) | 10A |
| Supply voltage (Ui) | 600V |
| Operating voltage AC-15 | 240V |
| Impulse withstand voltage (Uimp) | 6KV |
| Contact type | 2 NO contacts (normally open) |
| Number of selector positions | 2 locking positions |
| Action type | Rotary with lock |
| Number of terminals | 4 screw terminals |
| Mounting hole diameter | 22mm (7/8") |
| Maximum panel thickness | 8.5mm |
| Dimensions (L x W x H) | 39 x 29 x 66mm |
| Casing material | Polycarbonate and metal |
| Weight | 79g |
| Color | Black |
| EAN | 0781499725024 |
Warranty and support
The BD23 motor button benefits from a 24-month warranty in accordance with Romanian legislation for industrial electrical products. 30-day right of return without justification. Fast national courier delivery with telephone confirmation.
