Metallic Push Button 22mm with RETURN, 220V-10A, Red LED, ElectroAZ
Out of stock
-
Estimated delivery: 07 Jun - 11 Jun
22mm metal push button with red LED for industrial applications
The 22mm metal push button with momentary action and red LED is designed for industrial environments where mechanical strength and operational safety are essential. Powered at 220V and rated for 10A, it is suitable for automation panels, self-service car washes, vending machines, and HORECA equipment. The treated aluminum body ensures a long lifespan even under intensive use conditions.
What you get with this product
- Immediate visibility of the button's status due to the red LED light ring, visible even in low light conditions
- IP65 and IK09 protection — resistant to water splashes and vandalism, suitable for outdoor mounting or public spaces
- Flexible connection through dual NO and NC contact configuration on the same button, without additional parts
- Gold-plated silver alloy contacts — high conductivity and long-term resistance to oxidation
- Quick installation via M22 thread with included detachable nut and rubber gasket, no special tools required
- Compatible with standard 22mm industrial panels — direct replacement without modifications to the existing panel
How it works and how to install it
The momentary push button activates the circuit only while pressed, automatically returning to its initial position upon release — ideal behavior for momentary start or stop commands. Installation is done through the standard 22mm cutout: insert the button through the panel, tighten the nut on the back, and connect the 6 pins (2 for LED, 4 for NO/NC contact) according to the desired scheme. The entire process does not require a certified electrician if you are working on a panel disconnected from voltage.
Frequently Asked Questions
Does the button also work on DC current or only on 220V AC?
The button is rated for 220V AC / 10A. According to the visible marking on the product, the nominal voltage is 24VDC for the LED circuit — check the wiring diagram before use on DC.
Can I use this button in a car wash or a damp environment?
Yes, IP65 protection ensures water jet tightness, and IK09 class protects against mechanical impacts — suitable for such environments.
What is the difference between NO and NC contacts and which one should I use?
NO (normally open) closes the circuit only when pressed, NC (normally closed) breaks it when pressed. Choose NO for starting and NC for emergency stopping or fault signaling.
Technical Specifications
| SKU | EAZ-BP056 |
| Mounting diameter | 22 mm (M22 thread) |
| Rated voltage | 220V AC / 24V DC (LED) |
| Rated current | 10A |
| Actuator type | Momentary Push |
| LED color | Red |
| Number of pins | 6 pins (2 LED + 4 contact) |
| Contact types | 1NO + 1NC |
| Body material | Aluminum 304 / 316 |
| Contact material | Gold-plated silver alloy |
| Protection class | IP65 / IK09 |
| Operating pressure | 500 gf |
| Button face type | Flat, illuminated ring |
| Brand | ElectroAZ |
Warranty and Support
The product benefits from a 2-year legal warranty in accordance with current Romanian legislation. We accept returns within 30 days from the delivery date, without the need for justification. Delivery is made by express courier, with shipping confirmation and parcel tracking capability.
