IRS ON-OFF Button with LED 2 Contacts 220V
Out of stock
-
Estimated delivery: 07 Jun - 11 Jun
220V ON-OFF button with LED for simple control of electrical equipment
This push-button switch with 2 contacts and a red indicator LED operates at 220V AC and can be quickly installed in control panels for electrical equipment, production machinery, or household installations. The 6.3mm contacts ensure stable connections, and the light indicator shows when current is present, enhancing safety during use.
What you get with this product
- Integrated red LED that visually indicates the presence of current — you always know if the equipment is powered
- Switching capacity 10A at 220V AC — suitable for pumps, power tools, small motors, and industrial equipment
- Quick installation in the control panel — standard dimensions compatible with existing cutouts
- Robust plastic and metal construction — withstands intensive use in workshops and production areas
- Clearly marked ON-OFF contact — simple switching without intermediate positions, ideal for equipment requiring direct start/stop
- 6.3mm contacts — stable connections that eliminate the risk of overheating or intermittent contact
How it works and how to install it
The button is inserted into the control panel cutout and secured with the side clips. You connect the wires to the 2 x 6.3mm contacts according to your electrical circuit diagram. When pressed, the button switches between the ON position (current present, LED lit) and OFF (current interrupted, LED off). No special tools are needed for installation, just a screwdriver for tightening the contacts.
Frequently asked questions
Can I use this button for 16A equipment as stated on the housing?
The button can safely switch a maximum current of 10A according to specifications. The 16A marking on the housing represents the maximum mechanical limit, but the manufacturer's recommendation is 10A for optimal operation.
Does the LED light up when the button is ON or when there is current in the circuit?
The red LED lights up when the button is in the ON position and current is flowing through the circuit, acting as an active status indicator.
What are the dimensions of the cutout required for mounting?
The button mounts into a standard cutout for IRS KCD3 type switches, approximately 21x15mm. Check your panel dimensions before mounting.
Technical specifications
| Model | IRS-KCD3-2PR |
| Contact type | ON-OFF (I-0) |
| Number of contacts | 2 |
| Rated voltage | 220V AC |
| Maximum current | 10A |
| LED indicator | Red, integrated |
| Contact size | 6.3mm |
| Housing material | Plastic and metal |
| Actuation type | Push button |
| EAN | 0781499723495 |
Warranty and support
The product benefits from a 2-year warranty in accordance with Romanian law for manufacturing defects. You have the right to return within 30 days of receiving the order. Delivery is fast via national courier with telephone confirmation.
